CEXD-INTRBL01-A10-0002 Industrial Box PC · Intel Core Ultra X7 358H 16 Core 1.90 / 4.80 GHz
CEXD-INTRBL01-A10-0002 is an open robot development system by AAEON [An ASUS Co.] designed for robotic development, featuring an Intel® Core™ Ultra X7 358H processor.
The processor-integrated Intel® Arc™ GPU and NPU 5.0 with XMX AI engines deliver up to 180 TOPS AI performance, eliminating the need for a separate graphics card.
The GMSL camera interface transmits low-latency images over long cable distances and supports multi-camera perception in AMR, autonomous robot, and drone applications.
Four 2.5GbE ports, CAN bus, and a 22-pin GPIO provide direct connections to sensors and motor drivers. Powered by 19 ~ 24V DC.
Technical Specifications TECHNICAL SPECIFICATIONS
Performance
|
Processor (CPU)
|
Intel® Core™ Ultra X7 358H 16 Core 1.90 / 4.80 GHz | BM : 33510 |
|---|---|
|
Processor Family
|
Intel® Core™ Ultra X7 |
|
AI Accelerator | GPU
|
AI Accelerator Intel® Arc™ GPU + Intel® NPU 5.0 : 180 TOPS |
Connectivity
|
LAN/Ethernet Port Count
|
x 4 |
|---|---|
|
LAN/Ethernet Port Type
|
2.5GbE x 4, IEEE 1588 Support |
|
USB 3.2
|
Gen 1 x 4 |
|
USB 2.0
|
x 2 |
|
Video Output
|
HDMI x 1, DP x 1 |
|
Digital I/O
|
22-pin GPIO |
Physical
|
Supply Voltage
|
19V ~ 24V DC |
|---|---|
|
External Dimensions (mm)
|
137 x 135 x 86 |
System
|
Camera Input
|
GMSL x 2, 6 kanala kadar |
|---|---|
|
CANBus
|
x 1 |
Product at a Glance
CEXD-INTRBL01-A10-0002 — Industrial Box PC.
Video output: HDMI x 1, DP x 1. For connectivity it provides 4 Ethernet ports. Ports: USB 3.2 (Gen 1 x 4), 2 x USB 2.0. The device has external dimensions of 137 x 135 x 86 mm. Power input: 19V ~ 24V DC.
