IPC4-RT-AT86X-8128

Marka: IPC4 by ICC
Kategoriler:

Android 12 GMS supported rugged industrial tablet equipped with Mediatek MT6789 Octa-Core 2.2GHz processor.

It offers high visibility in outdoor use with its 8-inch 1280x800 resolution, 700 nit brightness PCAP touch screen.

It has 8 GB RAM and 128 GB eMMC storage capacity.

Wi-Fi 802.11 a/b/g/n/ac provides strong wireless connection with dual band 2.4G+5G support.

It offers clear imaging and document scanning with its front 5MP and rear 13MP autofocus cameras.

Bluetooth 5.1 (BLE) support provides long-distance wireless connections.

It offers long-term use with 3.7V/8500mAh battery.

It offers precise motion detection with G-Sensor support.

4G LTE connectivity provides global connectivity with broad cellular frequencies.

GNSS: Provides high accuracy positioning with GPS, GLONASS, BEIDOU, Galileo, QZSS, SBAS support.

Supports TF card up to 512GB, offers expandable storage.

USB 2.0 and Type-C ports ensure compatibility with peripheral devices.

The 3.5mm headphone jack is ideal for voice communication and media use.

Optional 2D barcode reader (Zebra SE4710) integration is available.

Standard accessories: Power adapter, USB cable, carrying strap.

Optional accessories: Docking Charger, 5V3A Car Charger, TP Resistant Film, Leather Cover, Back Strap, Shoulder Strap, car mount kit.

The optional vehicle mounting kit (VHM86) is compatible with the EM-T86X model.

With the ability to connect to 5G networks and advanced Bluetooth 5.1, IPC4 Rugged Tablets deliver fast data transfer and high-speed communication. These capabilities are essential for real-time data sharing and remote collaboration in industrial environments.

The ruggedized design of IPC4 Rugged Tablets ensures they keep working even in the harshest conditions. Resistant to drops, shock, and vibration, they're perfect for industries like logistics, construction, and public safety.

IPC4 Rugged Tablets support GPS and GLONASS positioning, making them ideal for industries that require accurate location tracking, such as logistics, land surveying, and fleet management. This feature enables real-time tracking, improving operational efficiency.

The large, high-resolution displays on the IPC4 Rugged Tablets provide a clear, detailed view of important data. Whether you're reviewing schematics, performing inspections, or interacting with applications, the displays provide high visibility and accuracy.

IPC4 Rugged Tablets are designed for long-term use with reliable performance. With durable features, powerful hardware, and versatile connectivity, these tablets provide an all-in-one solution for industrial applications, optimizing your workflow in any environment.

IPC4PRO-215WOD-C10-6412,IPC4PRO-215WOD-C10-6412,İPC4PRO-215WOD-C10-6412,ıPC4PRO-215WOD-C10-6412,iPC4PRO-215WOD-C10-6412,Industrial Tablet PC,IPC4-RT-AT86X-8128,Rugged Tablet PC

Özellikler


Ürün Kodu IPC4-RT-AT86X-8128
Screen size 8" TFT LCD
Resolution 1280 x 800
Screen Format 16 | 10
Brightness 700 cd/m²
Touch Type Projective Capacitive [P-CAP]
graphics processor ARM® Mali-G57
Cooling Without Fan
Processor [CPU] Mediatek MT6789 Octa-Core
DOĞRU Processor [CPU] Family
MediaTek RAM [System Memory]
8GB SSD/HDD/mSATA/M.2
128GB eMMC LAN/Ethernet
RJ45 x 1 (10/100Mbps) Optional USB 3.0
x1 USB Type-C
x1 RS 232 Serial Port
12PIN Pogo Pin x 1 Audio Output
3.5mm headphone jack x 1 + Built-in 8Ω/1W Waterproof Speaker x 1 Expansion Slot
Micro SD x 1 512GB Wireless
802.11 Bluetooth
BT5.1 (BLE) Front camera
5MP Rear Camera
13 MP Flashlight 4G - LTE
It comes with standard hardware. It will be delivered with an IMEI registration to BTK. IMEI registration is included in the price. GPS
(+) G Sensor
(+) 2D/QR Code Reader
Optional Zebra SE4710 Fingerprint reader
Optional Gyro-Sensor
(+) Battery
3.7V/8500mAh Battery Usage Time
(Optional) Docking charger DC86: DC86 docking charger VHM86: VHM86 vehicle mount SHIMMER
x1 Light Sensor
(+) Flash Light
(+) E-compass
(+) IC Card
DC 5V/3A Working temperature
-20°C ~ 60°C External Dimensions (mm)
715g Body Material
IP67 Certificates
CE | FCC | MIL-STD 810H Supported Operating Systems
